Scope of use:
If electronic products such as mobile phones and watches have requirements for water resistance and air leakage, the casing needs to be tested for air tightness.
advantage:
1. High precision, very sensitive to changes in induced pressure;
2. High stability, with automatic temperature compensation function;
3. The pneumatic connection is simple, which can realize quick loading and unloading;

| Project | Specification | Describe |
| Dimensions | Length 600mm*width 500mm*height 1500mm | |
| Detection pressure range | 1-100KPa | |
| Contrast sensor range | 0.1KPa-100KPa | |
| Pressure sensor resolution | 1PA | |
| Ambient temperature and humidity | Use temperature 5-40 ℃ below 80% HR | |
| Power requirements | 220V,50HZ | |
| Power | 0.2KW | |
| Air pressure requirements | 0.5-0.8MPA | |
| Weight | 120KG | |
| Time to change the model | 10-20 minutes | |
| Productivity | 200PCS-300PCS/(duplex) | Varies according to customer inactivity time |
|
