Use range:
Natural hot melt nut process for various plastic shells and electroplating shells.
advantage:
1. Easy to operate and high efficiency;
2. The machine is stable and reliable, with strong versatility and high safety factor.
| project | parameter | describe |
| Dimensions | Length 1200mm*width 920mm*height 1700mm | |
| Fits product specification | Length 180~246mm, width 85~169mm | |
| Equipment accuracy | 0.05mm | Module accuracy |
| Control System | PLC control | |
| Power requirements | 220V,50HZ | |
| Power consumption of the whole machine | 2.0KW | |
| Air pressure requirements | 0.4-0.6MPA | |
| Working heating temperature | ≤380℃ | |
| Capacity | 3000-3600PCS/H (number of nuts) | Depends on temperature and case material |
| Equipment cost recovery cycle | 6 months | According to 80% equipment utilization rate |
|
