Scope of application:
Various hardware mobile phone shells, plastic mobile phone shells, tablet shell accessories pressure maintaining process.
advantage:
1. The automatic operation of the equipment replaces labor.
2. It supports single-row and double-row feeding modes.
3. Support the forward and reverse working direction of the belt assembly line.
4. The production capacity can reach 1500pcs/H.
| Project | Parameter | describe |
| Machine dimensions | Length 850mm*width 600mm*height 1460mm | |
| Product size that can be attached | Length 180mm*width 85mm (mobile phone) Length 250mm*width 180mm (flat case) | Product Size |
| Equipment accuracy | ±0.1mm | |
| Control System | Automatic pressure keeping machine software V2.0 | Our company is soft |
| Power requirements | 220V，50HZ | |
| Power | 0.8Kw (1.8Kw with heating function on) | |
| Air pressure requirements | 0.5~0.8MPA | |
| Weight | 150KG | |
| Productivity | 1500Pcs/h | |
| Equipment cost recovery cycle | 4 months | Calculated at 80% equipment utilization rate |
|
