Scope of application:
Auxiliary materials for various mobile phone hardware shells, plastic shells and tablet computer shells.
advantage:
1. Fully automatic unmanned operation can be realized.
2. Equipped with upper and lower cameras, high precision and high production capacity, the production capacity can reach 1200PCS/H.
3. The manual pull wire labeling machine is easy to operate and can be combined with the traditional belt pull wire.

| project | parameter | describe |
| Dimensions | Length 850mm*width 850mm*height 1650mm | |
| Product size that can be attached | Length 180mm*width 85mm | |
| Equipment accuracy | ±0.04mm | |
| operating system | Yuehe line edge automatic paste accessories machine operating system | Our company is soft |
| Power requirements | 200V,50HZ | |
| Power | 1.4KW | |
| Air pressure requirements | 0.5-0.8MPA | |
| weight | 500KG | |
| Productivity | 1200PCS/H | |
| Equipment cost recovery cycle | 6 months | Calculated at 80% equipment utilization rate |
|
