Scope ofApplication
Process for attaching VC metal sheets on mobile phone structural components,VC metal sheets fed by vacuum formed trays
Advantage
1. High bonding accuracy: The comprehensive bonding material accuracyis within + 0.05m;
2. Simple structure, costsaving;
3. The height of the vacuum formed box matches the human body, making itconvenient to pick up and place products;
4.It can either be used to add additional materials or to attach the materials;
5.The conveyor belt has a flipping structure and can flip the steel plates.
| Equipment | VC Laminating Equipment |
| Model | YH017 |
| OverallDimension（L*W*H) | 1100mm*1455mm*1400mm |
| Weight | 800KG |
| Accuracy | ±0.05mm |
| AuxiliaryMaterials | VC Metal Sheet |
| RatedPower | 2.0KW |
| AirPressureRequirement | 0.5-0.8MPa |
| SingleYield | ≥99.5% |
| Capacity | 1000~1200Pcs/H |
| Cost-recoveryCycle | 6 months (calculated based on 80% utilization rate) |
|
